Miniwave Rework Station (mw10)
Approx. Price: Rs. 1.5lacs onwardsPower | 120 VAC, 60 Hz, 15 A optional 220 VAC, 50/60 Hz, 8 A |
Max solder temp | 6620F (3500C) |
Solder Capacity | 50 lbs (23 Kg) |
Compressed Air | (MW-10A only) : 60 PSI (4 bar) |
Dimensions | 16”x 26”x17” (406 x 660 x 432 mm) |
Warm-up time Approx | 30-45 min |
Weight | 30 lbs empty (13.5 kg), 80 lbs (36 Kg) with solder |
MW-10 | Solder Fountain |
MW-10A | Solder Fountain with blow - through air nozzle |
MW-UBF | Universal X, Y, & Z Board Fixture Option for board sizes up to 11” x 16.5” (280 x 420 mm) |
This is table- top selective soldering machine. The machine has programmable solder temp, wave height, wave duration. Solder wave fountain is created thru various sizes of nozzles suitable for different components. PCB is kept on lazer beam guided location on table, wave command is given by foot switch, solder wave touches component form below for programmed time. This machine is also used as thru hole PCB rework station.
Selective Soldering Machine
Approx. Price: Rs. 15lacs onwardsDisplay Type | Digital |
Frequency | 50 Hz |
Packaging Type | Carton Box |
Surface Finish | Polished |
Country of Origin | Made in India |
Automation Grade | Automatic |
Input Voltage | 230V |
This is table- top selective soldering machine. The machine has programmable solder temp, wave height, wave duration. Solder wave fountain is created thru various sizes of nozzles suitable for different components. PCB is kept on lazer beam guided location on table, wave command is given by foot switch, solder wave touches component form below for programmed time. This machine is also used as thru hole PCB rework station.
Solder Dross Recovery
Approx. Price: Rs. 6lacs onwardsCapacity | 1kg to 5kg |
Power | 230v, 50-60Hz, |
2Kw Dimensions | 530 x 510 x 575 mm |
Exhaust | 100mm / 4"dia |
Country of Origin | Made in India |
SRS 500 is the newest innovation in a long line of world-leading, revolutionary technology from EPS Worldwide Pvt Ltd. The new patented technology is totally new and exciting. The EPS 500 can recover 60-85% solder from the dross, which reduces solder consumption by up to 50+ percent - an unheard of reduction in the electronics production industry - and reduces dedrossing time by 75 percent and waste dross ofsite by up to 85 percent.
Wave Soldering Machine
Approx. Price: Rs. 2.5lacs onwardsMax Temp | 300 Degree C |
Packaging Type | Box |
Automation Grade | Automatic |
Material | Stainless Steel |
Max Input Current | 32 A |
Choice of coveyer system | Finger conveyer / pallet conveyer. |
Available in | Lead Free or Non Lead Free |
Compatible PCB width | upto 180mm, 300mm, 450mm and 600mm |
Controller | ISO Controller |
We are the leading entity in the entire market, popular for offering a wide range of Wave Soldering Machines. Our product can avail customers very easily from us at minimal cost which makes the product popular amongst valued customers. We use excellent quality raw material which enhance their serving life. The product is manufactured by modern machines based on latest technology with following the norms of industry parameters.
